1996 Buell S1 Lightning Motorcycle Workshop Repair & Service Manual (Searchable, Printable, Ipad-Ready Pdf) (MT049354)

1996 Buell S1 Lightning Motorcycle Workshop Repair & Service Manual (Searchable, Printable, Ipad-Ready Pdf) (MT049354)

• This manual presented for you in electronic format you can just print out the page you need then dispose of it when you have completed your task. This manual has detailed illustrations as well as step by step written instructions with the necessary diagrams or pictures. These manuals are your number one source for repair and service information, specifically written for the do-it-yourself as well as the experienced mechanics worldwide used to use this factory manual to fix your vehicle. Using this repair manual is an inexpensive way to keep your car working properly. it is this level of detail, along with illustrations, that guide the reader through each service, repairs, maintenance procedure.
• 1996 Buell S1 Lightning Motorcycle Workshop Repair & Service Manual (Searchable, Printable, iPad-ready PDF)

  Complete digital workshop service and repair manual written for the 1996 Buell S1 Lightning Motorcycle. All styles covered (all models, and engines). It is in the cross-platform PDF document format so that it works like a charm on all kinds of devices.

  This QUALITY manual is 100 COMPLETE and INTACT, no MISSING/CORRUPT pages/sections to freak you out! Buy from responsible seller and get INSTANT DOWNLOAD now without wasting your hard-owned money on uncertainty or surprise; this manual is exactly as described.

  PRODUCT DETAILS:

  Total Pages: 371 pages

  File Format: PDF (Windows & Mac & Linux)

  Language: English

  Delivery: instant download link displayed on checkout page & emailed to you after payment

  Protection: DRM-free; without any restriction

  Printable: Yes

  This COMPLETE official full workshop service repair manual for 1996 Buell S1 Lightning Sport Bike includes:

  * Detailed sub-steps expand on repair procedure information

  * Notes, cautions and warnings throughout each chapter pinpoint critical information.

  * Numbered instructions guide you through every repair procedure step by step.

  * Bold figure number help you quickly match illustrations with instructions.

  * Detailed illustrations, drawings and photos guide you through every procedure.

  * Enlarged inset helps you identify and examine parts in detail.

  * Numbered table of contents easy to use so that you can find the information you need fast.

  * This manual also makes it easy to diagnose and repair problems with your machines electrical system.

  * Troubleshooting and electrical service procedures are combined with detailed wiring diagrams for ease of use.

  * COMPLETE, Absolutely No Missing Pages!

  * Official Service INFORMATION You Can Count On!

  * Customer Satisfaction GUARANTEED!

  EXCERPT (1996 Buell S1 Lightning Motorbike Service/Repair Manual):

  TRANSMISSION CASE

  GENERAL

  The rear compartment of the left and right crankcase halves form the transmission case. An access cover (door) allows removal of transmission components without removing the engine or disassembling (splitting) the crankcase.

  REMOVAL

  1. Raise rear wheel off floor using REAR WHEEL SUPPORT STAND (Part No. B-41174).

  2. Remove rear fender. See FENDERS in Section 2.

  3. See Figure 6-12. Loosen rear axle nut (metric). Reduce tension on secondary drive belt by turning axle adjuster nuts on each side of swing-arm an equal number of turns counterclockwise. Move rear wheel as far forward as possible.

  4. Remove muffler. See EXHAUST SYSTEM in Section 2. Place a drain pan under the engine. Remove drain plug and drain lubricant from primary drive/transmission.

  5. Remove swing-arm/drive support screws and retaining nut. Remove sprocket cover, washer and spacer.

  6. See Figure 6-13. Place transmission in first gear. Remove two socket head screws (5) and lockplate (4).

  Figure 6-12. Secondary Drive Belt Adjustment b0249x6x

  1 CAUTION

  Transmission sprocket nut has left-hand threads. To prevent damage, turn nut clockwise to loosen and remove from main drive gear shaft.

  7. Remove transmission sprocket nut (3) from main drive gear shaft (1).

  8. Remove secondary drive belt from transmission sprocket (2). Remove transmission sprocket from main drive gear shaft (1).

  9. Remove primary cover. See PRIMARY CHAIN on page 6-3.

  10. Remove clutch assembly, primary chain and engine sprocket. See PRIMARY DRIVE/CLUTCH on page 6-10.

  11. See Figure 6-14. Lock transmission in gear. Remove countershaft TORX screw and retainer.

  12. See Figure 6-15. Detach spring (1) from groove in post (2).

  13. Remove retaining ring (10) and detent plate (9). You will need to use a new retaining ring for installation.

  14. Remove two locknuts (3) and washers (11) which attach shifter shaft assembly (6) to studs at transmission case. Remove shifter shaft assembly.

  15. Remove five access door bolts (7) and washers (8). Remove transmission assembly by pulling it straight outward, away from transmission case.

  CLEANING, INSPECTION AND REPAIR

  Thoroughly clean transmission compartment with cleaning solvent. Blow parts dry with compressed air. Inspect parts to determine if any must be replaced. Replace all parts that are badly worn or damaged.

  Neutral Indicator Switch

  See Figure 6-16. The neutral indicator switch is threaded into the transmission portion of the right crankcase half. See NEUTRAL INDICATOR SWITCH in Section 7 for testing, removal and installation procedures.
