• This manual presented for you in electronic format you can just print out the page you need then dispose of it when you have completed your task. This manual has detailed illustrations as well as step by step written instructions with the necessary diagrams or pictures. These manuals are your number one source for repair and service information, specifically written for the do-it-yourself as well as the experienced mechanics worldwide used to use this factory manual to fix your vehicle. Using this repair manual is an inexpensive way to keep your car working properly. it is this level of detail, along with illustrations, that guide the reader through each service, repairs, maintenance procedure.
• DUCATI MONSTER 696 2009 SERVICE WORKSHOP IPL REPAIR MANUAL

  IF YOU ARE LUCKIE ENOUGH TO OWN THE 696 THEN THIS IS WHAT YOU NEED.

  Massive workshop/service manual for the 696, inc parts catalogue, this will be the only manual you will need to buy as it covers everything, see the sections below.

  Also has over 1700 cystal clear iamges of the 696 parts.

  OPERATES ON WINDOWS 95,98,98SE,2000,NT,ME,XP,VISTA

  A – General

  1 – How to use this manual

  – Layout of the manual

  2 – Symbols – Abbreviations – References

  – Product specifications

  3 – Hazardous Products – Warnings

  – General safety rules

  – General maintenance indications

  B – Information about the model

  Identification data

  Identification data for the Monster 696

  C – Technical data

  1.1 – Technical specifications

  – General

  – Colours

  – Transmission

  – Timing system/valves

  – Cylinder/Piston

  – Gearbox

  – Cooling system

  – Front wheel

  – Front suspension

  – Rear wheel

  – Rear suspension

  – Hydraulic brakes

  – Charging system/alternator

  – Ignition system

  – Fuel system

  – Injection system

  – Lights/instrument panel

  1.2 – Dimensions

  2 – Fuel, lubricants and other fluids

  3 – Torque settings

  – Frame torque settings

  – Engine torque settings

  4 – Service tools

  – Specific tools for the engine

  – Specific tools for the frame

  D – Use and maintenance

  1 – Preliminary checks

  – Running-in precautions

  – Pre-ride checks

  2 – Starting – Engine warmup

  – Starting the engine

  3 – Routine maintenance table

  – Programmed maintenance plan: operations to be carried out by the dealer

  – Programmed maintenance plan: operations to be carried out by the customer

  4 – Maintenance operations

  – Checking the engine oil level

  – Changing the engine oil and filter cartridge

  – Checking valve clearances

  – Adjusting the valve clearances

  – Changing and cleaning the air filters

  – Changing the brake fluid

  – Draining the brake circuit

  – Filling the brake system with fluid

  – Changing the clutch fluid

  – Draining the clutch hydraulic circuit

  – Filling the clutch circuit

  – Adjusting the steering head bearings

  – Adjusting the chain tension

  – Checking brake pad wear and changing brake pads

  – Adjusting the throttle and choke cables

  – Adjusting the position of the gearchange and rear brake pedals

  – Adjusting the rear shock absorber

  5 – Diagnostic instruments

  – Description of the Ducati Diagnostic System tester

  – Tester power supply

  – DDS tester

  – Checking and adjusting timing belt tension

  – Adjusting the idle speed

  – Check the engine oil pressure

  – Cylinder compression test

  – Fuel pressure test

  – Immobilizer override procedure

  – Guided diagnosis

  – Testing the battery charging system

  – Icons table

  E – Fairings

  1 – Headlight fairing – rear-view mirrors

  – Removal of the rear-view mirrors

  – Refitting the rearview mirrors

  – Removal of the headlight fairing (696+)

  – Refitting the headlight fairing (696+)

  2 – Fairings

  – Removal of the fuel tank fairings

  – Refittings the fuel tank fairings

  3 – Seat

  – Removal of the seat

  – Refitting the seat

  – Removal of the tool tray

  – Refitting the tool tray

  4 – Front mudguard

  – Removal of the front mudguard

  – Refitting the front mudguard

  F – Controls – Devices

  1 – Throttle and choke controls

  – Adjusting the throttle and choke cables

  – Removal of the throttle twistgrip

  – Refitting the throttle twistgrip

  – Removal of the choke cable

  – Refitting the choke control

  2 – Hydraulic clutch control

  – Removal of the clutch master cylinder assembly

  – Refitting the clutch master cylinder assembly

  – Removal of the clutch slave cylinder

  – Refitting the clutch slave cylinder

  3 – Front brake control

  – Removal of the front brake master cylinder

  – Refitting the front brake master cylinder

  4 – Rear brake control

  – Removal of the rear brake master cylinder

  – Disassembly of the rear brake control

  – Refitting the rear brake master cylinder

  5 – Gearchange mechanism

  – Removal of the gearchange mechanism

  – Disassembly of the gearchange mechanism

  – Refitting the gearchange mechanism

  G – Wheels – Suspension – Brakes

  1 – Front wheel

  – Removal of the front wheel

  – Overhauling the front wheel

  – Refitting the front wheel

  2 – Front fork

  – Removal of the front forks

  – Overhauling the front forks

  – Refitting the front forks

  3 – Hydraulic front brake

  – Maintenance operations

  – Removal of the front brake system

  – Removal of the brake discs

  – Overhauling the front brake components

  – Refitting the front brake system

  4 – Rear wheel

  – Removal of the rear wheel

  – Overhauling the rear wheel

  – Refitting the rear wheel

  5 – Rear swingarm

  – Removal of the swingarm

  – Inspecting the swingarm pivot shaft

  – Checking swingarm endfloat

  – Refitting the swingarm

  6 – Hydraulic rear brake

  – Removal of the rear brake system

  – Refitting the rear brake system

  7 – Rear suspension

  – Rear suspension system

  – Removal of the rear shock absorber

  – Overhauling the rear shock absorber

  – Refitting the rear suspension

  8 – Final drive

  – Inspecting the final drive

  – Removal of the front sprocket

  – Refitting the front sprocket

  – Removal of the rear sprocket

  – Refitting the rear sprocket

  H – Frame

  1 – Handlebar

  – Removal of the handlebar

  – Refitting the handlebar

  2 – Steering

  – Adjusting the steering head bearings

  – Steering angle adjustment

  – Removal of the steering head components

  – Refitting the steering head components

  4 – Footrest brackets

  – Removal of the footrest brackets

  – Refitting the footrest brackets

  5 – Stands

  – Removal of the sidestand

  – Refitting the sidestand

  6 – Frame inspection

  – Disassembly of structural components and the frame

  – Removal of the frame

  – Removal of the rear subframe

  – Checking the frame

  – Reassembly of the rear subframe

  – Refitting the rear subframe

  7 – Tail light-number plate holder and locks

  – Removal of the tail light-protection-number plate holder assembly

  – Refitting the tail light-protection-number plate holder assembly

  – Removal of the seat release mechanism

  – Refitting the seat release mechanism

  – Removal of the number plate holder

  – Refitting the number plate holder

  L – Fuel/Exhaust System

  2 – Fuel tank

  – Removal of the fuel tank

  – Removal of the fuel tank filler cap

  – Refitting the filler cap

  – Removal of the fuel tank flange

  – Refitting the fuel tank flange

  – Refitting the fuel tank

  6 – Throttle body for pivoting fuel tank

  – Removal of the throttle body

  – Refitting the throttle body

  7 – Air intake

  – Removal of the airbox

  – Removal of the oil breather valve

  – Refitting the oil breather valve

  – Refitting the airbox

  8 – Exhaust system

  – Operating principle of the catalytic converter

  – Removal of the exhaust system

  – Refitting the exhaust system

  M – Fuel injection – ignition system

  1 – Description of the system

  – General information on the fuel injection-ignition system

  – Fuel circuit

  – Air circuit

  – Operating phases

  2 – Fuel injection-ignition system

  3 – System components

  – Electronic Control Unit (ECU)

  – Fuel injectors

  – Lambda sensor

  – Air pressure sensor

  – Temperature sensor

  – Spark plug

  – Coil

  – Throttle Position Sensor (TPS)

  – Rpm/timing sensor

  – Main and injection relays

  N – Engine

  1 – Removalrefitting of the engine assembly

  – Removal of the engine

  – Refitting the engine

  2.1 – Lubrication system: oil pump

  – Removal of the oil pump

  – Disassembly of the oil pump

  – Reassembly of the oil pump

  – Refitting the oil pump

  4.1 – Cylinder head assemblies: checks and adjustments

  – Checking and adjusting valve clearances

  – Checking the engine timing

  4.2 – Cylinder head assemblies: timing belt covers/timing system

  – Removal of the timing belt covers

  – Removal of the timing system assembly

  – Disassembly and reassembly of the timing belt pulleys

  – Refitting the timing system assembly

  – Refitting the timing belt covers

  4.3 – Cylinder head assemblies: camshafts

  – Removal of the intake manifolds

  – Refitting the intake manifolds

  – Removal of the inner timing belt covers

  – Removal of the valve covers

  – Refitting the valve covers

  – Removal of the camshafts

  – Inspecting the camshafts

  – Checking the oil seals

  – Refitting the camshafts

  – Refitting the camshaft end caps

  4.4 – Cylinder head assemblies: valves – rocker arms

  – Removal of the cylinder head assembly

  – Removal of the rocker arms, shims and valves

  – Overhaul of cylinder head components

  – Refitting the cylinder head assembly

  – Refitting the rocker arms, shims and valves

  – Refitting the cylinder heads

  5 – Cylinder/piston assemblies

  – Removal of the cylinder/piston assembly

  – Overhaul of the cylinder barrel/piston components

  – Refitting the cylinder/piston assembly

  6.1 – Clutch assembly: APTC wet clutch

  – Description of the APTC clutch assembly

  – Removal of the APTC clutch

  – Disassembly of the clutch hub-plates-centre assembly

  – Overhaul and inspection of the APTC clutch components

  – Reassembly of the clutch hub-plates-centre assembly

  – Refitting the APTC clutch

  6.2 – Clutch assembly: clutch-side crankcase cover

  – Removal of the clutch-side crankcase cover

  – Disassembly of the clutch-side crankcase cover

  – Reassembly of the clutch-side crankcase cover

  – Refitting the clutch-side crankcase cover

  6.3 – Clutch assembly: primary drive gears

  – Removal of the primary drive gears

  – Refitting the primary drive gears and checking backlash

  7.1 – Gearbox assembly: gearchange mechanism

  – Removal of the gearchange mechanism

  – Disassembly of the gear selector mechanism

  – Disassembly of the gear interlock plunger and pawl assembly

  – Refitting the gear interlock plunger and pawl assembly

  – Reassembly of the gearchange mechanism

  – Refitting the gearchange mechanism

  7.2 – Gearbox assembly: gearbox shafts

  – Removal of the gearbox assembly

  – Disassembly of the gearbox shafts

  – Overhaul of the gearbox

  – Inspection of the gear selector forks

  – Inspection of the gear selector drum

  – Reassembly of the gearbox shafts

  – Reassembly of the gearbox

  8 – Flywheel – alternator

  – Removal of the alternator-side crankcase cover

  – Disassembly of the alternator-side crankcase cover

  – Removal of the flywheel/alternator assembly

  – Checking the flywheel/alternator assembly

  – Refitting the flywheel-alternator assembly

  – Reassembly of the alternator-side crankcase cover

  – Refitting the alternator-side crankcase cover

  9.1 – Crankcase assembly: external components

  – Removal of external components

  – Refitting the external components

  – Removal of the timing gears

  – Refitting the timing gears

  – Removal of the starter motor idler gear

  – Refitting the starter motor idler gear

  9.2 – Crankcase assembly: crankcase halves

  – Separation of the crankcase halves

  – Overhaul of the crankcase halves

  – Overhaul of the main bearings

  – Reassembly of the crankcase halves

  – Shimming the shafts

  – Reassembly of the crankcase halves

  9.3 – Crankcase assembly: crankshaft/connecting rods assembly

  – Removal of the crankshaft/connecting rods assembly

  – Disassembly of the crankshaft/connecting rods assembly

  – Overhaul of the connecting rods

  – Reassembly of the connecting rods

  – Refitting the crankshaft/connecting rod assembly

  P – Electrical system

  1 – Wiring diagram

  – Key to wiring diagram

  – Wiring colour codes

  – Key to fusebox

  – Routing of wiring on frame

  – Plate A

  – Plate B

  – Plate C

  – Plate D

  – Plate E

  – Plate F

  – Plate G

  – Plate H

  – Plate J

  – Plate K

  – Plate L

  – Plate M

  – Plate N

  – Plate O

  – Plate P

  – Plate Q

  – Plate R

  – Plate S

  – Plate T

  – Plate U

  – Plate V

  2 – Battery charging system

  – Checking the battery charging system

  – Recharging the battery

  – Topping up the electrolyte

  – Battery

  – Battery support

  – Alternator

  – Rectifier-regulator

  3 – Electric starting system

  – Electric starting system

  – Starter motor

  – Starter contactor

  4 – Lights and indicating devices

  – Renewal of the headlight

  – Changing bulbs

  – High beam headlights relay

  – Headlight aim

  5 – Indicating devices

  – Checking the indicating devices

  – Changing light bulbs

  6 – Protection and safety devices

  – Checking protection and safety device components

  – Checking the fuses

  7 – Instruments

  – Instrument panel

  – Instrument panel system

  – Display settings and functions

  8 – Immobilizer and transponder

  9 – Diagnostic instruments

  – Using a multimeter to check the electrical systems

  =============================================================

  The parts catalogue, covers the sections below:

  001 WORKSHOP SERVICE TOOLS

  001a WORKSHOP SERVICE TOOLS

  001b DDS TESTER

  001c WORKSHOP SERVICE TOOLS

  002 GEARCHANGE CONTROL

  003 GEARBOX

  004 CLUTCH

  005 CLUTCH-SIDE CRANKCASE COVER

  006 CONNECTING RODS

  007 CYLINDERS – PISTONS

  008 TIMING SYSTEM

  009 FILTERS AND OIL PUMP

  010 CRANKCASE HALVES

  011 ALTERNATOR-SIDE CRANKCASE COVER

  012 ELECTRIC STARTING AND IGNITION

  013 CYLINDER HEAD : TIMING SYSTEM

  014 VERTICAL CYLINDER HEAD

  015 HORIZONTAL CYLINDER HEAD

  016 INTAKE MANIFOLDS

  017 STANDS

  018 ELECTRICAL SYSTEM

  019 BATTERY SUPPORT

  020 EXHAUST SYSTEM

  021 INSTRUMENT PANEL – HEADLIGHT FAIRING

  022 HEADLIGHT

  023 NUMBER PLATE HOLDER – TAIL LIGHT

  024 FRONT FORKS

  025 FRONT AND REAR WHEELS

  026 HANDLEBAR AND CONTROLS

  027 CLUTCH CONTROL

  028 FRONT BRAKE

  029 REAR BRAKE

  030 FRAME

  031 GEARCHANGE LEVER – FOOTREST

  032 SWINGARM AND DRIVE CHAIN

  033 REAR SUSPENSION

  034 AIR INTAKE – OIL BREATHER

  035 FUEL TANK

  036 FUEL SYSTEM

  037 SEAT

  038 FUEL TANK (COVER)

  ========================================================

  As you can see its massive and not just that but in languages:

  Italiano

  English

  Deutsch

  Francais

  Espaniol

  Portuese

  USA

  Japan
