• This manual presented for you in electronic format you can just print out the page you need then dispose of it when you have completed your task. This manual has detailed illustrations as well as step by step written instructions with the necessary diagrams or pictures. These manuals are your number one source for repair and service information, specifically written for the do-it-yourself as well as the experienced mechanics worldwide used to use this factory manual to fix your vehicle. Using this repair manual is an inexpensive way to keep your car working properly. it is this level of detail, along with illustrations, that guide the reader through each service, repairs, maintenance procedure.
• Piper PA-28-151 & PA-28-161 Warrior, Warrior II, Warrior III Aircraft Maintenance Set Parts and Service Manuals for the following Piper Planes:

  PA-28-151 Cherokee Warrior

  PA-28-161 Cherokee Warrior II

  PA-28-161 Warrior III

  All files are Adobe pdf files & use Adobe Acrobat reader to access information (which is available for free on the web)

  * INSTANT DOWNLOAD – NO WAITING

  * LANGUAGE: English

  * FORMAT: Zipped PDF

  * COMPATIBLE: All Versions of Windows & Mac

  * SEARCHABLE – BOOKMARKED – INDEXED

  All files are Bookmarked & have a Search Function for ease of use

  THE ZIPPED FILE INCLUDES:

  – Service Repair Manual

  – Illustrated Parts Catalog

  __________________________________

  SERVICE MANUAL INFORMATION:

  Revision Date: 01/01/09

  This service manual is effective for PA-28-151 Cherokee Warrior airplanes, serial numbers 28-7415001 thru 28-7715314; PA-28-161 Cherokee Warrior II airplanes, serial numbers 28-7716001 thru 28-8616057 and serial numbers 2816001 thru 2816105 (less 2816066); PA-28-161 Warrior III airplanes, serial numbers 2816110 thru 2816119.

  This encompasses the following model years:

  Model – Sub-Model – Serial Numbers – Model Year

  PA-28-151 CHEROKEE WARRIOR 28-7415001 thru 28-7415713 – 1974

  28-7515001 thru 28-7515459 – 1975

  28-7615001 thru 28-7615445 – 1976

  28-7715001 thru 28-7715314 – 1977

  PA-28-161 CHEROKEE WARRIOR II 28-7716001 thru 28-7716323 – 1977

  28-7816001 thru 28-7816695 – 1978

  28-7916001 thru 28-7916617 – 1979

  28-8016001 thru 28-8016382 – 1980

  28-8116001 thru 28-8116342 – 1981

  28-8216001 thru 28-8216236 – 1982

  28-8316001 thru 28-8316112 – 1983

  28-8416001 thru 28-8416131 – 1984

  28-8516001 thru 28-8516099 – 1985

  28-8616001 thru 28-8616057, – 1986

  2816001 thru 2816010 (less 2816002) 2816002, – 1987

  2816011 thru 2816036 (less 2816029 thru 2816033) 2816029 thru 2816033, – 1988

  2816037 thru 2816075 (less 2816066) 2816076 thru 2816094 – 1989

  2816095 thru 2816099 – 1990

  2816100 thru 2816103 – 1992

  2816106 thru 2816109 – 1993

  2816104 and 2816105 – 1994

  PA-28-161 WARRIOR III 2816110 only – 1994

  2816111 thru 2816119 – 1995

  SECTIONS INCLUDE:

  0- Introduction

  I- Airworthiness Limitations

  II- Handling & Servicing

  III- Inspection

  IV- Structures

  V- Surface Controls

  VI- Not used

  VII- Landing Gear & Brakes

  VIII- Powerplant

  IX- Fuel System

  X- Instruments

  XI- Electrical System

  XII- Electronics

  XIII- Heating & Ventilation System

  XIV- Accessories & Utilities

  __________________________________

  PARTS CATALOG INFORMATION:

  Revision Date: 09/10/09

  This illustrated Parts Catalog provides simple, positive identification of replacement parts for the Piper Model PA-28-151/161 manufactured by the Piper Aircraft Corporation of Vero Beach, Florida.

  1. The catalog is divided into thirteen major sections as follows:

  a. Section I to Xll inclusive contains all replacement parts for the complete airplane. Each section is subdivided and each division includes an illustration and a parts listing.

  b. Section XIII is the Miscellaneous Group. This group includes an illustration and parts list for the Placards and Exterior Stencils, a listing of the Optional Equipment Kits, Repair kits and Special Tools, and a listing of Miscellaneous Hardware and Consumables.

  The serial numbers of the aircraft covered by this Parts Catalog are as follows:

  Serial Numbers of the 1974 PA-28-151 WARRIOR Models are 28-7415001 thru 28-7415703.

  Serial Numbers of the 1975 PA-28-151 WARRIOR Models are 28-7515001 thru 28-7515449.

  Serial Numbers of the 1976 PA-28-151 WARRIOR Models are 28-7615002 thru 28-7615435.

  Serial Numbers of the 1977 PA-28-151 WARRIOR Models are 28-7715001 thru 28-7715314.

  Serial Numbers of the 1977 PA-28-161 WARRIOR ll Models are 28-7716002 thru 28-7716323.

  Serial Numbers of the 1978 PA-28-161 WARRIOR ll Models are 28-7816001 thru 28-7816680.

  Serial Numbers of the 1979 PA-28-161 WARRIOR ll Models are 28-7916001 thru 28-7916598.

  Serial Numbers of the 1980 PA-28-161 WARRIOR ll Models are 28-8016001 thru 28-8016373.

  Serial Numbers of the 1981 PA-28-161 WARRIOR ll Models are 28-8116001 thru 28-8116322.

  Serial Numbers of the 1982 PA-28-161 WARRIOR ll Models are 28-8216001 thru 28-8216226.

  Serial Numbers of the 1983 PA-28-161 WARRIOR ll Models are 28-8316001 thru 28-8316112.

  Serial Numbers of the 1984 PA-28-161 WARRIOR ll Models are 28-8416001 thru 28-8416131.

  Serial Numbers of the 1985 PA-28-161 WARRIOR ll Models are 28-8516001 thru 28-8516099.

  Serial Numbers of the 1986 PA-28-161 WARRIOR ll Models are 28-8616001 thru 28-8616057, 2816001 thru 2816010 (less 2816002).

  Serial Numbers of the 1987 PA-28-161 WARRIOR ll Models are 2816002, 2816011 thru 2816036 (less 2816029 thru 2816033).

  Serial Numbers of the 1988 PA-28-161 WARRIOR ll Models are 2816029 thru 2816033, 2816037 thru 2816075 (less 2816066).

  Serial Numbers of the 1989 PA-28-161 WARRIOR ll Models are 2816076 thru 2816094.

  Serial Numbers of the 1990 PA-28-161 WARRIOR ll Models are 2816095 thru 2816099.

  Serial Numbers of the 1992 PA-28-161 WARRIOR ll Models are 2816100 thru 2816103.

  Serial Numbers of the 1993 PA-28-161 WARRIOR ll Models are 2816106 thru 2816109.

  Serial Numbers of the 1994 PA-28-161 WARRIOR ll Models are 2816104 and 2816105.

  Serial Numbers of the 1994 PA-28-161 WARRIOR llI Models are 2816110.

  Serial Numbers of the 1995 PA-28-161 WARRIOR llI Models are 2816111 thru 2816119
